产品详情
Machine Parameters
| Specification | |
| The precision after bending | ±0.05mm |
| The planeness | 0.25mm |
| The min head length of the bending | 1.8mm |
| The min end length of the bending | 1.8mm |
| The max bending angle | 90 degree |
| The min radius for 90 degree angle | 0.5mm |
| Material applied | 0.45mm/0.53mm/0.71mm/1.05mm |
| Power supply | 220/380V 50/60HZ |
| Air pression | 0.6MPA |
| size | 2600*850*1500mm(L*W*H) |
| Weight | 460KG |
Advantage
Individual Bending, simple operation
Special Mold Design, Adequate Bending With High Precision
Adjustable Bending And Feed Speed For Various Bending Requirements Of Different Graphs
Auto Identification Of Straight Or Circular Cutter To Guarantee Correct Cutting Delivery Action
Special Circular Cutter Rest Installed For Different Rotary Direction
Different Types Of Bending Molds Can Be Replaced Within 10 Seconds
Original Drive And Control Units Imported From Abroad To Guarantee Precision And Long Service Life
Suitable For The Bending Of Cutting Molds To Make Velvet Toys, figured Pattern Card box, card Sign, plastic Toy Packing Cover
